io.module

P+E1M00000000
io.module

  • Caractéristiques générales

    io.module is the new device developed by Carel for data acquisition and activation of outputs managed by a Carel supervisor or generic Building Management System (BMS). This product supports both the Carel protocol and the Modbus protocol, and features:

    • 4 temperature inputs, configurable as NTC or PT1000;
    • 4 digital inputs
    • 2 active probe inputs, which can be set as 4-20 mA, 0-5 V or 0-10 V.



    The device is equipped with 6 electromechanical relays, which can be controlled by the BMS or associated with alarm logic. The serial communication parameters, including the choice of the protocol used, can be set using the easy-to-access switches on io.module.

  • Plus

    Versatility

    Can be used as an input-output expansion for both Carel and third-party supervisory systems using the standard Modbus protocol.

    Alarms

    • Management of high and low temperature alarms and other values, with optional notification delays;
    • Possibility to create groups of alarms, which can also control the relays for activating external devices.

    Easy configuration

    Wide range of inputs for temperature and generic values, 6 relay outputs, all easily configurable and manageable via Modbus.

    Configurable logic

    Possible associations between probes, digital inputs and relays.

    Higher accuracy

    Possibility to individually calibrate each probe so as to optimise accuracy across the operating range.






Documentation

Technical

  • 2D/3D drawings
    * Entries are ordered by date
    Code Description Langue Date * Version
    Code 2d-3d io.module

    		 Description 2D-3D drawings io.module

    		 Langue ALL

    		 Date 27/04/2023

    		 Version R00

  • Manuals
    * Entries are ordered by date
    Code Description Langue Date * Version
    Code +0300142IE

    		 Description io.module Modulo Input/Output su RS485

    		 Langue ENG  ITA

    		 Date 27/06/2024

    		 Version 1.0

  • Technical Leaflets
    * Entries are ordered by date
    Code Description Langue Date * Version
    Code +0500109IE

    		 Description P+E1M*: io.module modulo Input/Output su RS485 Input/output module on RS485

    		 Langue ENG  ITA

    		 Date 12/04/2024

    		 Version 1.1

    Code +0500109FR

    		 Description P+E1M*: io.module - module Entrée/Sortie sur RS485 / Input/output module on RS485

    		 Langue ENG  FRE

    		 Date 12/04/2024

    		 Version 1.1
